M8 Anti-Vibration Mount - Female-Female Bobbin (Weight Rating 15.8kg)
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 1 | £2.53 | £3.04 |
| 2 - 249 | £2.52 | £3.03 |
| 250 - 499 | £2.34 | £2.81 |
| 500 - 999 | £2.16 | £2.59 |
| 1000 - 2499 | £1.98 | £2.38 |
| 2500 + | £1.80 | £2.16 |
£3.04 / each
.png)
Product Specification
| Diameter | 30mm |
| Height | 30mm |
| Thread Size | M8 |
| Thread Length | N/A |
| Type | Female to Female |
| Shore Hardness | 45 IRHD |
| Weight Rating | 15.8kg |
| Deflection | 2.6mm |
| Material | Zinc Steel & Natural Rubber |
Frequently Bought Together
Total Price: £0.00
M8 Female to Female Anti Vibration Mount | 30mm x 30mm Bobbin | 15.8kg Weight Rating | Zinc Steel & Natural Rubber
Providing isolation for automation frames, the M8 female to female rubber bobbin mount is suited to frames, panels and equipment covers that need a resilient fixing.
Because both sides are internally threaded, the bobbin can be fixed with chosen bolt lengths to suit panel thickness, access restrictions or maintenance requirements. A 2.6mm deflection value helps the mount cushion movement while maintaining a stable fixing point. It suits projects needing a natural rubber isolator, bonded metal mount or resilient machinery fixing.
Common Applications
- Fitting operator control boxes
- Supporting production line attachments
- Cushioning access panels
- Isolating conveyor sensors
M8 30mm x 30mm Female to Female Anti Vibration Mount Dimensions
- Diameter: 30mm
- Height: 30mm
- Thread Size: M8
- Type: Female to Female
- Shore Hardness: 45 IRHD
- Weight Rating: 15.8kg
- Deflection: 2.6mm
- Material: Zinc Steel & Natural Rubber
Fixing Style Guidance
Choose a female to female bobbin when both sides need to accept separate bolts and a lower profile mount is preferred before assembly. The Zinc Steel & Natural Rubber construction helps combine secure threaded fixing with rubber isolation for machinery, panels and equipment frames.
View our full Anti Vibration Mounts Range.
Need help or buying in bulk? Call 01233 713581 for support with sizing, load rating and fixing style selection.
