Snap Fit Hole Plugs
All of our Snap Fit Plugs are made from a durable Low Density Plastic (LDPE), and come in a red finish from standard. These plugs are an ergonomic yet cost effective solution to prevent the damage, weathering, and ingress of dirt to both panel or threaded holes, and are recommended for use during transport, storage, etc.
Our Plastic Snap Fit Plugs are easy to both remove and install thanks to the pull tab on their head and ability to be screwed in/out for a range of applications.
Snap fit plastic plugs are ideal for sealing and protecting holes in metal panels, tubing, pipework and automotive components, making them a reliable choice for manufacturing and engineering environments.
We stock these Snap Fit Plugs for a range of panel or threaded holes in a wide range of sizes between M10 & M42 (10-42mm). However, we can always offer custom sizing where required. For all currently available sizes, or to request a sample, please see the table below. You can also get in touch with a member of our team through the phone, live chat or by using our Contact Us page.
Key Product Features:
- Manufactured from a strong LDPE Plastic
- Easy to install and remove
- For filling in excess holes
- Ergonomic design
Commonly Used For:
- As plugs for threaded and panel holes
- As screw in plugs to protect an application
Find the Right Snap Fit Hole Plug
Need help matching a Snap Fit Hole Plug to your panel or enclosure? Our team can advise on mounting hole diameter, panel thickness and suitable push-fit plug options for your application. Call 01233 713 581 for sizing advice, quotations or larger order enquiries.
Trade customers can also apply for a Vital Parts Business Account for trade pricing, product samples, credit account options and dedicated account support.
Frequently Asked Questions
Snap Fit Hole Plugs are designed to close unused or unwanted openings in panels, enclosures and fabricated components. Once installed, they provide a neat protective finish while covering exposed panel holes.
Snap fit plugs use flexible retaining features that compress as the plug enters the hole before expanding behind the panel. This creates a secure mechanical fit without requiring adhesives or separate fasteners.
Start by measuring the diameter of the mounting hole, then check the compatible panel thickness. Both measurements are important for achieving a secure fit and ensuring the plug sits correctly against the panel surface.
These plastic hole plugs are widely used for electrical enclosures, control panels, machinery, automotive assemblies and fabricated equipment where unused openings need to be safely covered.
Most snap fit hole plugs are designed for straightforward push-in installation. Once aligned with a compatible opening, they can be pressed into position with the retaining features holding the plug securely against the panel.
