M10 x 280mm Coach Bolt & Nut (DIN 603) - Part Thread | CE Certified 4.8 Steel BZP
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £1.69 | £2.03 |
| 100 - 999 | £1.51 | £1.81 |
| 1000 - 9999 | £1.28 | £1.54 |
| 10000 + | £1.06 | £1.27 |
£2.03 / each
Product Specification
| Thread Size | M10 |
| Length | 280mm |
| Thread Length | 45mm |
| Pitch | 1.50mm |
| Material | 4.8 Steel BZP |
| Head Diameter | 24.65mm |
| Head Height | 5.38mm |
| Square Width | 10mm |
| Standard | DIN 603 |
Frequently Bought Together
Total Price: £0.00
M10 x 280mm Coach Bolt & Nut (DIN 603) | 45mm Thread Length | CE Certified 4.8 Steel BZP
This M10 x 280mm Coach Bolt & Nut is a CE certified 4.8 Steel BZP fixing designed for access panels and guards, including removable covers, security grilles and protective barriers. Manufactured to DIN 603, it uses a round domed head and square neck to help prevent rotation during tightening.
The square neck allows the bolt to grip timber fibres or a matching square aperture before final tightening. This makes the M10 x 280mm size useful for assemblies where only one side is easy to access during installation. The included DIN 555 nut gives a compatible threaded fixing for the DIN 603 coach bolt. The CE certified specification supports consistent use in regulated supply chains and trade counters. This size suits projects where a stronger fixing is needed without moving to larger heavy section hardware.
Common Applications
- Maintaining large timber members, multi-layer brackets and reinforced frames using an M10 metric coach bolt.
- Access panels and guards where the round head needs to remain neat and low snag.
- Fastening brackets to wooden frames with a supplied DIN 555 nut for a complete fixing set.
- Repairing long through-bolted joints that need more reach on 280mm coach bolt installations.
M10 x 280mm Coach Bolt & Nut Dimensions
- Thread Size: M10
- Length: 280mm
- Threaded Length: 45mm
- Pitch: 1.50mm
- Head Diameter: 24.65mm
- Head Height: 5.38mm
- Square Width: 10mm
- Standard: DIN 603
- Material: 4.8 Steel BZP
- Colour: BZP
View our full range of Hex Head Screws and Bolts.
