M27 x 50mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 49 | £0.03 | £0.03 |
| 50 - 99 | £0.02 | £0.02 |
| 100 + | £0.01 | £0.01 |
Product Specification
| Thread Size | M27 |
| Length | 50mm |
| Threaded Length | Fully Threaded |
| Pitch | 3.00mm |
| Head Diameter | 40.0mm |
| Head Height | 27.0mm |
| Drive | H19 |
| Head Style | Cap Head |
| Material | A4 Stainless Steel |
Frequently Bought Together
Total Price: £0.00
M27 x 50mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
Designed for rail and transport maintenance, this M27 x 50mm hex drive cap screw combines a H19 hex socket with a 40mm cap head for controlled tightening into threaded components.
The marine grade A4 stainless steel construction supports clean counterbored presentation, while the M27 thread and 50mm length make it suitable for attaching steel brackets. The A4 stainless specification makes this a useful choice for harsher environments compared with standard indoor fixings. It can also be specified as a high tensile screw where Dimensions are required.
Common Applications
- Motor and pump mounting
- Marine hardware installation
- Serviceable cover plates
- Rail maintenance fixtures
M27 x 50mm Socket Cap Screw Dimensions
- Thread Size: M27
- Length: 50mm
- Threaded Length: Fully Threaded
- Pitch: 3.00mm
- Head Diameter: 40mm
- Head Height: 27mm
- Drive: H19
- Material: A4 Stainless Steel
- Head Style: Cap Head
- Standard: DIN 912
Fastener Selection Note
Socket cap screws are commonly chosen for threaded assemblies where an Allen key drive offers cleaner access than an external hex head.
