Liquid Tight Blanking Plugs

Liquid tight blanking plugs, also known as rubber blanking plugs or waterproof hole plugs, are specialised sealing components designed to provide complete protection against water, oil, and environmental ingress. These TPE rubber plugs are engineered to seal unused mounting holes and access points in panels, enclosures, and equipment across multiple UK industries including marine, automotive, electrical, telecommunications, and outdoor infrastructure. The primary function of these liquid tight plugs is to create an impermeable barrier that prevents moisture, dust, chemicals, and debris from entering sensitive systems whilst maintaining IP68 waterproof standards for submersible applications.

Manufactured from premium Thermoplastic Elastomer (TPE) rubber, these liquid tight blanking plugs deliver exceptional durability and chemical resistance. Available in Shore A hardness ratings of 75 and 85, they provide the perfect balance between flexibility for easy installation and structural integrity for long-term sealing performance. Each plug features a UL94V-0 flammability rating and UL certification, ensuring compliance with stringent UK safety standards for outdoor and industrial applications. The innovative tapered shank design allows for effortless hand installation without additional tools, whilst the temperature resistance range of -60°C to 135°C makes them suitable for extreme British weather conditions and industrial environments.

Available Materials and Style Options:

• TPE Thermoplastic Elastomer rubber construction
• Shore A hardness options: 75 and 85 durometer ratings
• Standard colour: Professional black finish
• UL94V-0 flame retardant rating for safety compliance
• Tapered shank design for secure, tool-free installation
• Multiple mounting hole diameters: 12.7mm, 15.9mm, 22.2mm, 25.4mm, 27.8mm and 34.9mm
• Various head diameters and panel thickness accommodations

Key Features and Benefits:

• IP68 waterproof rating providing complete submersible protection
• Oil-tight sealing for hydraulic and automotive applications
• Exceptional temperature resistance from -60°C to 135°C (-81°F to 275°F)
• UL certified for outdoor installations and harsh environments
• Chemical resistance against acids, alkalis, and industrial solvents
• UV stabilised TPE material prevents degradation from sunlight exposure
• Vibration resistant design maintains seal integrity under mechanical stress
• Quick installation by hand without requiring specialised tools or equipment
• Long service life reduces maintenance costs and replacement frequency
• Certified by Canadian Standards Association for North American compliance

Common UK Use Cases:

• Marine applications: Sealing hull penetrations, deck equipment, and navigation systems on boats and offshore platforms around UK coastal waters
• Electrical enclosures: Protecting control panels, junction boxes, and outdoor electrical installations from British weather conditions
• Automotive industry: Blanking unused access holes in vehicle body panels, engine compartments, and electronic control units
• Industrial machinery: Sealing openings in manufacturing equipment, hydraulic systems, and process control installations across UK factories
• Telecommunications infrastructure: Weatherproofing cable entry points in outdoor communications cabinets and transmission equipment

Related Vital Parts Products:

• Liquid Tight Break Through Plugs - IP67/68 rated plugs with breakthrough membrane for cable insertion
• Cable Glands - Comprehensive range including metric, PG, and NPT threaded options for cable sealing
• Rubber Grommets - Flexible sealing solutions for cable protection and threading applications
• Strain Relief Cable Glands - IP rated glands providing both sealing and cable strain protection
• Liquid Tight Hole Plugs - Extended range of sealing plugs including IP65, IP67, and IP68 ratings
