Double Tab Washers DIN 463
Double Tab Washers DIN 463 are locking washers designed to help prevent nuts, bolts and other threaded fasteners from loosening due to vibration, movement or repeated loading. Manufactured to DIN 463, these washers feature two locking tabs that can be bent into position after installation, creating a positive mechanical lock.
One tab is typically located against a fixed component or locating surface, while the second tab is bent against a flat of the nut or bolt head. This arrangement physically restricts rotation, making DIN 463 Double Tab Washers suitable for applications where maintaining fastener security is important.
What are Double Tab Washers?
Double Tab Washers, also known as two-tab locking washers or tab lock washers, are a form of mechanical locking washer. Unlike friction-based locking methods, the tabs are physically bent into position after the fastener has been tightened, helping to prevent unwanted rotation.
Their simple construction makes them suitable for machinery, assemblies and engineering applications where fasteners may otherwise loosen through vibration or operational movement.
Technical Specifications:
-
Standard: DIN 463
-
Type: Double Tab Locking Washer
-
Suitable for use with metric threaded fasteners
-
Two bendable locking tabs
-
Available in a range of sizes and material options
Applications:
DIN 463 Double Tab Washers are commonly used within:
-
Industrial machinery
-
Mechanical assemblies
-
Automotive and transport equipment
-
Manufacturing equipment
-
Gearboxes and transmission assemblies
-
Maintenance and repair applications
-
Equipment exposed to vibration or repeated movement
Benefits:
-
Provides a positive mechanical locking method
-
Helps prevent fasteners from rotating or loosening
-
Particularly useful in vibration-prone applications
-
Simple to install using conventional tools
-
Manufactured to the recognised DIN 463 standard
-
Available in multiple sizes to suit different metric fasteners
Why Buy from Vital Parts?
At Vital Parts, we supply DIN standard fasteners, washers and locking components for a wide range of industrial and engineering applications. Our Double Tab Washers DIN 463 are available in a selection of sizes to suit different fastening requirements.
For help selecting the correct Double Tab Washers DIN 463 for your application, please contact our sales team on 01233 713581
