M42 x 150mm Hex Bolt - Part Threaded (DIN 931) | Marine Grade A4 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £123.03 | £147.63 |
| 100 - 999 | £110.72 | £132.87 |
| 1000 + | £93.50 | £112.20 |
Product Specification
| Thread Size | M42 |
| Pitch | 4.50mm |
| Length | 150mm |
| Threaded Length | 96mm |
| Material | A4 Stainless Steel |
| Across Flats | 65mm |
| Head Height | 26.4mm |
| Head Style | Hex Head |
| Standard | DIN 931 |
Frequently Bought Together
Total Price: £0.00
M42 x 150mm Hex Head Bolt DIN 931 | A4 Stainless Steel
This M42 x 150mm hex head screw style bolt is made for automation equipment, giving a clean externally driven fixing for metal sections, brackets and equipment frames. Its A4 Stainless Steel material choice is well suited to outdoor, coastal and wash-down equipment where corrosion resistance is important. It is a practical option for buyers searching for a part threaded hexagon bolt with measured DIN 931 geometry.
The partially threaded design is useful where the shank passes through one component and the threaded end clamps against the mating part, helping reduce movement in bracketed assemblies. With a 4.50mm pitch and 65mm across flats head, it is easy to specify for heavy engineering, structural equipment and specialist plant assemblies.
Common Applications
- Aligning robot cell frames in automation equipment
- Replacing linear rail supports using M42 metric hardware
- Fixing mounting plates where A4 Stainless Steel is specified
- Upgrading machine enclosure panels requiring DIN 931 part threaded bolts
M42 x 150mm Hex Head Bolt DIN 931 Dimensions
- Thread Size: M42
- Length: 150mm
- Threaded Length: 96mm
- Pitch: 4.50mm
- Across Flats: 65mm
- Head Height: 26.4mm
- Material: A4 Stainless Steel
- Standard: DIN 931
- Head Style: Hex Head
Compatible Fasteners
Most commonly used with Washers and Nuts, these products are used to hold fasteners in place and join two or more parts together. We also offer Socket Head Screws
Our hex head screws are also available as fully threaded Hex Head Screws.
View our full Hex Head Bolts DIN 931 range.
