M24 x 40mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 49 | £4.15 | £4.98 |
| 50 - 99 | £3.77 | £4.53 |
| 100 + | £3.19 | £3.83 |
Product Specification
| Thread Size | M24 |
| Length | 40mm |
| Threaded Length | Fully Threaded |
| Pitch | 3.00mm |
| Head Diameter | 36.0mm |
| Head Height | 24.0mm |
| Drive | H19 |
| Head Style | Cap Head |
| Material | A4 Stainless Steel |
Frequently Bought Together
Total Price: £0.00
M24 x 40mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
Designed for production lines, this M24 x 40mm socket head cap screw combines a H19 hex socket with a 36mm cap head for controlled tightening into threaded components.
The marine grade A4 stainless steel construction supports dependable service replacement, while the M24 thread and 40mm length make it suitable for fastening precision fixtures. The A4 stainless specification makes this a useful choice for harsher environments compared with standard indoor fixings. It can also be specified as a DIN 912 fastener where Dimensions are required.
Common Applications
- Control cabinet installation
- Vehicle panel assemblies
- Machine base assembly
- Metal housing assembly
M24 x 40mm Socket Cap Screw Dimensions
- Thread Size: M24
- Length: 40mm
- Threaded Length: Fully Threaded
- Pitch: 3.00mm
- Head Diameter: 36mm
- Head Height: 24mm
- Drive: H19
- Material: A4 Stainless Steel
- Head Style: Cap Head
- Standard: DIN 912
Fastener Selection Note
Socket cap screws are commonly chosen for threaded assemblies where an Allen key drive offers cleaner access than an external hex head.
View our full Socket Cap Screws DIN 912 Range.
