M16 x 35mm Socket Grub Screw - Flat Point (DIN 913) | A2 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £1.06 | £1.27 |
| 100 - 499 | £0.88 | £1.06 |
| 500 - 999 | £0.78 | £0.93 |
| 1000 - 4999 | £0.68 | £0.81 |
| 5000 + | £0.59 | £0.71 |
Product Specification
| Thread Size | M16 |
| Length | 35.0mm |
| Pitch | 2.00mm |
| End Type | Flat |
| Drive | H8 |
| Standard | DIN 913 / ISO 4026 |
| Material | A2 Stainless Steel |
Frequently Bought Together
Total Price: £0.00
M16 x 35mm Flat Point Socket Grub Screw | H8 Drive | A2 Stainless Steel
Built around the DIN 913 / ISO 4026 standard, this M16 x 35mm socket set screw is suited to electrical enclosure builds. It combines a compact threaded body with a flat point for reliable seating inside collars, hubs and adjustable parts. Engineers often select this headless set screw when keeps internal fixings compact around panels and covers in hinge blocks, mounting rails and enclosure accessories.
The A2 stainless grade is a strong choice where a clean self-colour finish and reliable corrosion resistance are required for regular industrial use. Because the screw is headless, it can be recessed into a threaded component to reduce snagging and keep the surrounding assembly clear. It is well suited to general stainless grub screw requirements across manufacturing and maintenance teams.
Common Applications
- Hinge blocks, mounting rails and enclosure accessories using a M16 x 35mm flat point set screw
- Food processing machinery brackets and stops
- Laboratory frames and instrument housings
- Stainless mechanical assemblies needing a flush screw
Key Features and Benefits
- Flat point helps distribute load on the contact face rather than biting sharply into the retained part
- Headless body can sit below the surface for clean mechanical assemblies
- H8 socket gives controlled Allen key installation in restricted spaces
- DIN 913 / ISO 4026 manufacture supports repeatable sizing across maintenance and OEM requirements
M16 x 35mm A2 Stainless Steel Flat Point Socket Grub Screw Dimensions
- Thread Size: M16
- Length: 35mm
- Pitch: 2.00mm
- End Type: Flat
- Drive: H8
- Material: A2 Stainless Steel
- Colour: Self-colour
- Standard: DIN 913 / ISO 4026
Further Reading
View our full range of Socket Grub Screw Flat DIN 913 here: Socket Grub Screw Flat DIN 913.
