M12 x 100mm Hex (Non Serrated) Flange Bolt (DIN 6921) | A2 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £1.59 | £1.91 |
| 100 - 499 | £1.52 | £1.83 |
| 500 - 999 | £1.33 | £1.60 |
| 1000 + | £1.08 | £1.30 |
Product Specification
| Thread Size | M12 |
| Thread Length | 100mm |
| Pitch | 1.75mm |
| Material | A2 Stainless Steel |
| Across Flats | 16mm |
| Head Height | 11.5mm |
| Flange Diameter | 26.6mm |
| Standard | DIN 6921 |
| Head Style | Flanged Hex Head |
Frequently Bought Together
M12 x 100mm Hex (Non Serrated) Flange Bolt (DIN 6921) | Marine Grade A4 Stainless Steel
Total Price: £0.00
M12 x 100mm Flanged Hex Head Bolt (DIN 6921) | A2 Stainless Steel
This M12 x 100mm flanged hex head bolt in A2 Stainless Steel is chosen for assembling support frames, ducts and service housings. Manufactured to DIN 6921, it uses a 26.6mm flange diameter and 16mm across flats to give a practical hex driven fixing for HVAC equipment.
The built-in washer face helps protect the surrounding surface, making the fixing useful for equipment that sees vibration, routine servicing or repeated adjustment. The A2 Stainless Steel finish should be matched to the working environment before installation.
Common Applications
- Hvac Equipment: assembling support frames, ducts and service housings.
- Panel Mounting: reducing the need for loose washers on flat surfaces.
- Workshop Use: helps maintain a broad bearing face on thin sheet or bracketed materials.
- Trade Maintenance: supporting quick specification from thread size and length.
M12 x 100mm Flanged Hex Head Bolt Dimensions
- Thread Size: M12
- Thread Length: 100mm
- Pitch: 1.75mm
- Flange Diameter: 26.6mm
- Head Height: 11.5mm
- Across Flats: 16mm
- Standard: DIN 6921
- Head Style: Flanged Hex Head
- Material: A2 Stainless Steel
Installation Advice
Use the head height and flange diameter together when checking clearance below guards, covers or equipment housings. Tighten using the correct socket or spanner size and follow the required torque setting for the assembly.
Related Fasteners
Most commonly used in conjunction with Washers and Nuts, these products help hold fasteners in place and join two or more parts together. We also offer Socket Head Screws
For a standard non-flanged head, view our Hex Head Bolts DIN 931. For a fully threaded hex option, view our Hex Set Screws DIN 933.
View our full range of Flanged Hex Head Bolts DIN 6921.
