M8 x 160mm Hex Bolt - Part Threaded (DIN 931) | Marine Grade A4-80 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £1.88 | £2.26 |
| 100 - 999 | £1.68 | £2.02 |
| 1000 + | £1.07 | £1.29 |
Product Specification
| Thread Size | M8 |
| Pitch | 1.25mm |
| Length | 160mm |
| Threaded Length | 28mm |
| Material | A4-80 Stainless Steel |
| Across Flats | 13mm |
| Head Height | 5.5mm |
| Head Style | Hex Head |
| Standard | DIN 931 |
Frequently Bought Together
Total Price: £0.00
M8 x 160mm Hex Head Bolt DIN 931 | A4-80 Stainless Steel
Designed for steel fabrication projects, this M8 x 160mm DIN 931 hex bolt combines a plain shank section with a threaded end for strong alignment through prepared holes. The A4-80 Stainless Steel specification makes it suitable for marine, coastal and chemical environments where stronger corrosion resistant stainless fastening is required. This makes the M8 x 160mm hex head bolt useful when a standard metric fastening has to match existing drawings.
DIN 931 sizing improves interchangeability across maintenance stores, OEM builds and fabrication projects where consistent metric hardware is needed. The A4-80 Stainless Steel grade should be selected around the working environment and load expectations for the assembly.
Common Applications
- Upgrading fabricated brackets in steel fabrication projects
- Securing welded frames using M8 metric hardware
- Mounting support plates where A4-80 Stainless Steel is specified
- Assembling maintenance access assemblies requiring DIN 931 part threaded bolts
M8 x 160mm Hex Head Bolt DIN 931 Dimensions
- Thread Size: M8
- Length: 160mm
- Threaded Length: 28mm
- Pitch: 1.25mm
- Across Flats: 13mm
- Head Height: 5.5mm
- Material: A4-80 Stainless Steel
- Standard: DIN 931
- Head Style: Hex Head
Compatible Fasteners
Most commonly used with Washers and Nuts, these products are used to hold fasteners in place and join two or more parts together. We also offer Socket Head Screws
Our hex head screws are also available as fully threaded Hex Head Screws.
View our full Hex Head Bolts DIN 931 range.
