M24 x 80mm Set Screw - Hex Head (DIN 933) | Marine Grade A4-80 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £8.52 | £10.22 |
| 100 - 999 | £7.24 | £8.69 |
| 1000 + | £3.83 | £4.60 |
Product Specification
| Thread Size | M24 |
| Length | 80mm |
| Pitch | 3.00mm |
| Material | A4-80 Stainless Steel |
| Across Flats | 36mm |
| Head Height | 15.40mm |
| Standard | DIN 933 |
| Head Style | Hex Head |
Frequently Bought Together
Total Price: £0.00
M24 x 80mm Hex Set Screw | DIN 933 | A4-80 Stainless Steel
This A4 stainless steel hex set screw is supplied in a M24 thread size with a 80mm length, making it suitable for repeatable fastening in construction brackets.
The A4-80 stainless steel specification offers strong corrosion resistance with a higher tensile grade for exposed equipment, marine projects and demanding external assemblies. With a 3mm thread pitch and 36mm across flats size, this screw can be specified confidently for repairs, new builds and batch assembly work.
Common Applications
- Electrical enclosures, control cabinets and instrument housings
- Inspection benches, test rigs and adjustable jig construction
- Stainless assemblies in external, washdown or clean working areas
- Construction fixings, steel support plates and equipment bases
Why Choose This Fully Threaded Hex Screw?
- Fully threaded 80mm body helps support consistent engagement through the joint
- 36mm across flats head allows fitting with common spanners and socket tools
- The medium length gives flexibility across plate stacks, spacers and general engineering assemblies.
M24 x 80mm Hex Set Screw Dimensions
- Thread Size: M24
- Length: 80mm
- Pitch: 3mm
- Across Flats: 36mm
- Head Height: 15.4mm
- Material: A4-80 Stainless Steel
- Standard: DIN 933
- Head Style: Hex Head
Most commonly used in conjunction with Washers and Nuts, these products help hold fasteners in place when joining two or more parts together. We also offer Socket Head Screws
Need a partially threaded alternative? View our Hex Head Bolts range for DIN 931 style fixings.
View our full Hex Set Screws DIN 933 range.
