8.4mm Bonded Sealing Washer (19mm OD) | A2 Stainless Steel EPDM
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 49 | £0.49 | £0.59 |
| 50 - 99 | £0.42 | £0.50 |
| 100 - 249 | £0.31 | £0.37 |
| 250 - 499 | £0.23 | £0.27 |
| 500 - 999 | £0.19 | £0.23 |
| 1000 - 4999 | £0.15 | £0.18 |
| 5000 + | £0.12 | £0.15 |
£0.59 / each
.png)
Product Specification
| Internal Diameter | 8.4mm |
| Outside Diameter | 19.0mm |
| Total Thickness | 2.8mm |
| Metal Thickness | 0.8mm |
| Seal Thickness | 2mm |
| Seal Material | EPDM Rubber |
| Material | A2 Stainless Steel |
Frequently Bought Together
Total Price: £0.00
8.4mm x 19mm Bonded Sealing Washer | 2.8mm | A2 Stainless Steel & EPDM
This 8.4mm x 19mm bonded sealing washer is suited to general construction and fabricated metal assemblies where a conventional flat washer alone would not provide a sealing element. The EPDM Rubber section is permanently bonded to the A2 Stainless Steel washer to create a single-piece sealing component.
What Are Bonded Sealing Washers?
EPDM Bonded Washers are designed for applications where the fastener hole needs additional protection from moisture, air or compatible fluids. EPDM is widely used for weather-resistant sealing while the stainless steel washer supports the clamping force.
Our gasket washers are available in multiple internal and outside diameters for matching different compatible fasteners and sealing footprints.
Common Applications
- Automotive Components: Helps seal suitable fastener points on panels, brackets and equipment where EPDM compatibility is appropriate.
- Electrical Panels: Supports sealed bolt and screw points on suitable outdoor boxes, covers and fabricated enclosures.
- Plant Equipment: Provides a combined sealing and load-spreading washer for suitable industrial fixing points.
- Fabricated Metalwork: Helps reduce ingress paths around bolts and screws in compatible sheet-metal assemblies.
8.4mm x 19mm Bonded Sealing Washer Dimensions
- Internal Diameter: 8.4mm
- Outside Diameter: 19.0mm
- Total Thickness: 2.8mm
- Metal Thickness: 0.8mm
- Seal Thickness: 2mm
- Material: A2 Stainless Steel
- Seal Material: EPDM Rubber
Key Benefits
- EPDM Rubber provides weather, ozone and UV resistance for suitable sealing applications.
- Metal ring spreads clamping load while the bonded rubber helps seal around the fixing hole.
- 19mm outside diameter provides the washer's overall bearing and sealing footprint.
- 0.8mm metal thickness provides the specified A2 Stainless Steel supporting section.
Browse more seal washers to compare internal diameters and outside diameters for different compatible fasteners. If you need help selecting the correct size, call us on 01233 713581.
