Ergonomic Clamping Handle - HW141

Product code: HW141
View All Specifications
Orange M5 x 20mm Ergonomic Clamping Handles
Orange M5 x 20mm Ergonomic Clamping Handles
Orange M5 x 20mm Ergonomic Clamping Handles
Orange M5 x 20mm Ergonomic Clamping Handles
Orange M5 x 20mm Ergonomic Clamping Handles
Orange M5 x 20mm Ergonomic Clamping Handles
Quantity
Unit Price
(ex. VAT)
Unit Price
(inc. VAT)
1 - 9 £1.97 £2.36
10 - 24 £1.60 £1.92
25 - 49 £1.48 £1.77
50 - 99 £1.27 £1.53
100 - 499 £1.03 £1.24
500 + £0.88 £1.06

£2.36 / each


Up to 36 units
Available
Vital Parts Tick
Order now for dispatch within 2 days.
36 + units
Available for production
Average production time 14 + days.
Vital Parts - Here to make bulk ordering easy.

Product Specification
Thread Size M5 x 20mm
Thread Type Male
Handle Length 43mm
Height 29mm
Shank Diameter 12mm
Handle Material Nylon
Thread Material Steel
Handle Colour Orange
Button Colour Black

Next Day or Standard Delivery available via DHL or Royal Mail.
Order by 4pm (UK) for same day dispatch, Monday to Thursday or 2pm Friday.

Larger Order?

Call our sales team on

01233 713581


Frequently Bought Together

Total Price: £0.00

M5 x 20mm Male Ergonomic Clamping Handle | 43mm Handle | Orange/Black Nylon | Steel Thread

Designed for machine building, jigs and fixtures, this M5 x 20mm ergonomic clamping lever uses a male threaded stud to clamp or secure a compatible component. The ergonomic Nylon handle can be repositioned through the indexed mechanism when surrounding equipment limits continuous rotation. The Steel threaded component provides a robust fixing for general machinery, tooling and industrial adjustment.

What Are Ergonomic Clamping Handles?

Adjustable Ergonomic Clamping Handles are used on machinery, jigs and fixtures where components need to be locked, released or repositioned by hand. The indexed mechanism supports repeated adjustment in confined or frequently accessed locations.

Different applications may suit other threaded clamping handles, including alternative handle shapes, materials and male or female thread options.

Common Applications

  • Packaging Machinery: Allows guides, stops and adjustable components to be tightened and repositioned by hand.
  • Inspection Fixtures: Provides repeatable clamping for gauges, test rigs and adjustable checking equipment.
  • Workshop Machinery: Secures suitable guards, brackets and accessories where regular hand adjustment is required.
  • Assembly Equipment: Supports quick manual clamping on suitable fixtures, locators and production aids.

M5 x 20mm Male Ergonomic Clamping Handle Dimensions

  • Thread Size: M5 x 20mm
  • Thread Type: Male
  • Handle Length: 43mm
  • Height: 29mm
  • Shank Diameter: 12mm
  • Handle Colour: Orange
  • Button Colour: Black
  • Handle Material: Nylon
  • Thread Material: Steel

Key Benefits

  • M5 x 20mm male thread provides the specified connection for the clamping assembly.
  • 29mm overall height defines the installed handle profile.
  • Orange Nylon handle with Black button gives the specified colour combination.
  • Indexed ratchet mechanism allows the lever position to be reset after tightening.

See more male ratchet clamping handles for industrial clamping and adjustment applications. For product-selection support, speak with our team on 01233 713581.

Please call for any enquiries!
Mon - Thurs 8.30 am - 5.30 pm
Fri 8.30 am - 3.30 pm
✕
