M4 x 10mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
Product code:
HSC912-M4-10-A4
View All Specifications
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 999 | £0.03 | £0.04 |
| 1000 - 4999 | £0.03 | £0.03 |
| 5000 + | £0.02 | £0.02 |
£0.04
/ each
Quantity:
Product Specification
| Thread Size | M4 |
| Length | 10mm |
| Threaded Length | Fully Threaded |
| Pitch | 0.70mm |
| Head Diameter | 7.0mm |
| Head Height | 4.0mm |
| Drive | H3 |
| Head Style | Cap Head |
| Material | A4 Stainless Steel |
Next Day or Standard Delivery available via DHL or Royal Mail.
Order by 4pm (UK) for same day dispatch, Monday to Thursday or 2pm Friday.
Frequently Bought Together
+
+
Total Price: £0.00
M4 x 10mm Hex Socket Cap Screw (DIN 912) | Marine Grade A4 Stainless Steel
Suitable for rail and transport maintenance, this M4 x 10mm threaded cap screw is a DIN 912 cap screw used where access, torque control and repeatable fixing are important.
With A4 stainless steel and a H3 drive, the screw is suited to fastening automation rails where installers need reliable fit in precision assemblies without using an external spanner.
Common Applications
- Storage system assembly
- Serviceable cover plates
- Metal housing assembly
- Electrical enclosure hardware
M4 x 10mm Socket Cap Screw Dimensions
- Thread Size: M4
- Length: 10mm
- Threaded Length: Fully Threaded
- Pitch: 0.70mm
- Head Diameter: 7mm
- Head Height: 4mm
- Drive: H3
- Material: A4 Stainless Steel
- Head Style: Cap Head
- Standard: DIN 912
Fastener Selection Note
For best results, check the thread size, pitch, length and available thread engagement against the tapped component before installation.
View our full Socket Cap Screws DIN 912 Range.
