M4 Nyloc Nut (DIN 985) | Marine Grade A4 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £0.03 | £0.04 |
| 100 - 999 | £0.03 | £0.03 |
| 1000 - 9999 | £0.02 | £0.02 |
| 10000 + | £0.01 | £0.01 |
£0.04 / each
.png)
Product Specification
| Thread Size | M4 |
| Thread Pitch | 0.70mm |
| Material | A4 Stainless Steel |
| Across Flats | 7mm |
| Height | 5mm |
| Standard | DIN 985 |
Frequently Bought Together
Total Price: £0.00
M4 Thin Nyloc Hex Nut | 0.70mm Pitch | DIN 985 | A4 Stainless Steel
Made to DIN 985, this M4 nylon lock nut uses a nylon locking ring to add resistance to rotation after installation. The 7mm across-flats dimension allows standard tool engagement while the 5mm height provides a compact alternative to taller nylon lock nut formats. The A4 stainless steel construction provides enhanced corrosion resistance for suitable outdoor, coastal and marine fastening applications.
What Are DIN 985 Nyloc Nuts?
Thin Nyloc Hex Nuts provide a lower-height locking option than taller nylon insert nuts. Their DIN 985 format combines a conventional metal hex body with a nylon locking ring which helps maintain the joint without relying on a separate lock washer.
Other compact locking sizes are available in our nyloc nuts range, while DIN 982 locknuts are available where a higher nut profile is preferred.
Common Applications
- Machinery: Helps secure bolts on guards, brackets and equipment where vibration could loosen a conventional nut.
- Automotive Assemblies: Provides a locking nut for suitable brackets, panels and mechanical fixings exposed to movement.
- Electrical Equipment: Secures compatible bolts in control panels, enclosures and equipment frames.
- General Engineering: Provides a reusable locking fastener for fabricated assemblies, maintenance work and mechanical builds.
M4 DIN 985 Thin Nyloc Hex Nut Dimensions
- Thread Size: M4
- Thread Pitch: 0.70mm
- Across Flats: 7mm
- Height: 5mm
- Material: A4 Stainless Steel
- Standard: DIN 985
Key Benefits
- M4 metric thread provides the specified fastening size.
- 7mm across-flats dimension provides the stated hex body width for tool engagement.
- DIN 985 manufacture provides a recognised dimensional standard for thin nylon insert locknuts.
- Compact body height suits assemblies where a taller locknut may create clearance issues.
We can help you compare thread sizes, material grades and locking nut styles on 01233 713581.
