6.3mm x 45mm Slotted Countersunk AB Self Tapping Screw (DIN 7982C) | A2 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £1.43 | £1.72 |
| 100 - 499 | £0.78 | £0.94 |
| 500 - 999 | £0.65 | £0.78 |
| 1000 + | £0.55 | £0.66 |
Product Specification
| Thread Size | 6.3mm |
| Length | 45.0mm |
| Material | A2 Stainless Steel |
| Drive Type | Torx |
| Drive | T30 |
| End Type | AB |
| Head Diameter | 12.4mm |
| Head Height | 3.80mm |
| Standard | DIN 7982C |
Frequently Bought Together
Total Price: £0.00
6.3mm x 45mm Torx Countersunk AB Self Tapping Screw DIN 7982C | A2 Stainless Steel
Chosen for compact panel builds, this 6.3mm x 45mm countersunk assembly screw helps with attaching cabinet hardware in display hardware work.
The 12.4mm head diameter provides a practical seating area and the T30 drive helps maintain control during installation. A2 stainless steel supports corrosion resistance and consistent performance in display hardware work where improved vibration resistance is required.
Common Applications
- Assembling instrument housings
- Fixing protective corner guards
- Attaching steel guide plates
- Repairing production equipment
6.3mm x 45mm Torx Countersunk Screw DIN 7982C Dimensions
- Thread Size: 6.3mm
- Length: 45mm
- Head Diameter: 12.4mm
- Head Height: 3.80mm
- Drive: T30
- End Type: AB
- Drive Type: Torx
- Standard: DIN 7982C
- Material: A2 Stainless Steel
Range Guidance
Select the correct thread size, length, drive and material for the panel thickness and environment before ordering. Pilot hole suitability should be checked against the material being fixed.
For more sizes, view our Countersunk Self Tapping Screws Range. Related fixing options are available in Self Tapping Screws.
