M4 x 25mm Hex Socket Cap Screw (DIN 912) | A2 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 999 | £0.03 | £0.04 |
| 1000 - 4999 | £0.03 | £0.03 |
| 5000 + | £0.02 | £0.02 |
Product Specification
| Thread Size | M4 |
| Length | 25mm |
| Threaded Length | Fully Threaded |
| Pitch | 0.70mm |
| Head Diameter | 7.0mm |
| Head Height | 4.0mm |
| Drive | H3 |
| Head Style | Cap Head |
| Material | A2 Stainless Steel |
Frequently Bought Together
Total Price: £0.00
M4 x 25mm Hex Socket Cap Screw (DIN 912) | A2 Stainless Steel
Designed for HVAC equipment, this M4 x 25mm socket head cap screw combines a H3 hex socket with a 7mm cap head for controlled tightening into threaded components.
The A2 stainless steel equivalent to 304 construction supports secure fastening in threaded components, while the M4 thread and 25mm length make it suitable for repairing workshop machinery. The A2 stainless specification offers good corrosion resistance for workshop, machinery and cabinet applications. It can also be specified as a DIN 912 fastener where Dimensions are required.
Common Applications
- Vehicle panel assemblies
- Inspection station hardware
- Threaded component installation
- Maintenance replacement fixings
M4 x 25mm Socket Cap Screw Dimensions
- Thread Size: M4
- Length: 25mm
- Threaded Length: Fully Threaded
- Pitch: 0.70mm
- Head Diameter: 7mm
- Head Height: 4mm
- Drive: H3
- Material: A2 Stainless Steel
- Head Style: Cap Head
- Standard: DIN 912
Fastener Selection Note
Socket cap screws are commonly chosen for threaded assemblies where an Allen key drive offers cleaner access than an external hex head.
View our full Socket Cap Screws DIN 912 Range.
