M12 x 1.5mm Threaded Brass Cable Gland (IP68) 3 - 7mm Cable | Nickel Plated - Waterproof
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 9 | £4.37 | £5.24 |
| 10 - 49 | £4.25 | £5.10 |
| 50 - 99 | £4.04 | £4.85 |
| 100 + | £3.50 | £4.20 |
£5.24 / each
Product Specification
| Thread Size | M12 x 1.5mm |
| Cable Diameter | 3.0 - 7.0mm |
| Thread Length | 5.0mm |
| Total Length | 23 - 30mm |
| Style | Straight-through |
| Material | Brass |
| Colour/Finish | Nickel Plated |
| IP Rating | IP68 |
Frequently Bought Together
Total Price: £0.00
M12 x 1.5mm Nickel Plated Brass Threaded Cable Gland – 3 - 7mm Cable (IP68)
Designed for cable entry through commercial wiring enclosures, this M12 x 1.5mm nickel-plated brass cable gland is suitable for cables measuring 3 - 7mm. The nickel plated finish and 5mm threaded section distinguish this option from other threaded cable fittings. Its stated ingress classification is IP68.
What Are Threaded Brass Cable Glands?
A threaded cable gland sits at the point where a cable enters a panel or enclosure. Its cable-gripping section supports strain relief while the gland provides a controlled passage through the opening. This Brass version suits the specified 3 - 7mm cable size and M12 x 1.5mm connection.
Common Applications
- Industrial wiring: Fit a M12 x 1.5mm gland where a 3 - 7mm cable passes into an industrial electrical enclosure.
- Junction boxes: Introduce cables through matching threaded box entries without leaving an unprotected cut-out.
- Automation equipment: Provide cable entry for wiring connected to machine sensors and controllers.
- Outdoor cabinets: Select an IP68-classified cable fitting for suitably designed external electrical housings.
M12 x 1.5mm Threaded Brass Cable Gland Dimensions
- Thread Size: M12 x 1.5mm
- Cable Diameter: 3.0 - 7.0mm
- Thread Length: 5.0mm
- Total Length: 23 - 30mm
- IP Rating: IP68
- Style: Straight-through
- Material: Brass
- Colour/Finish: Nickel Plated
Key Benefits
- Accepts the specified 3 - 7mm cable diameter range for accurate gland selection.
- Provides a 5mm thread length for checking panel entry compatibility.
- Nickel-plated brass construction offers a metal gland body with the specified finish.
- IP68 ingress protection classification for the stated gland design.
Browse more nickel-plated brass cable glands to compare thread connections and cable diameter options. If you need help selecting the correct size, call us on 01233 713581.
