M24 Nyloc Nut (DIN 985) | A2 Stainless Steel
| Quantity |
Unit Price
(ex. VAT)
|
Unit Price
(inc. VAT)
|
|---|---|---|
| 1 - 99 | £2.02 | £2.43 |
| 100 - 499 | £1.75 | £2.10 |
| 500 - 999 | £1.35 | £1.62 |
| 1000 + | £1.14 | £1.37 |
£2.43 / each
.png)
Product Specification
| Thread Size | M24 |
| Thread Pitch | 3.00mm |
| Material | A2 Stainless Steel |
| Across Flats | 36mm |
| Height | 24mm |
| Standard | DIN 985 |
Frequently Bought Together
Total Price: £0.00
M24 Thin Nyloc Hex Nut | 3.00mm Pitch | DIN 985 | A2 Stainless Steel
Made to DIN 985, this M24 locking hex nut uses a nylon locking ring to add resistance to rotation after installation. The 36mm across-flats dimension allows standard tool engagement while the 24mm height provides a compact alternative to taller nylon lock nut formats. The A2 stainless steel construction provides good corrosion resistance for general engineering, machinery and suitably exposed fastening applications.
What Are DIN 985 Nyloc Nuts?
Nyloc Nuts are metal hex nuts fitted with a nylon insert that grips the mating thread as the bolt passes through. This added friction creates a prevailing torque which helps the nut resist loosening under vibration, movement and repeated service conditions.
The same locking principle is available across our thin nyloc nuts. For a taller body design, see the related high nylon lock hex nuts range.
Common Applications
- Pumps and Motors: Helps maintain bolted joints on suitable equipment exposed to vibration and repeated operation.
- Furniture and Frames: Provides a compact locking nut for metal frames, brackets and adjustable furniture components.
- Transport Equipment: Supports secure fastening on suitable panels, brackets and serviceable mechanical assemblies.
- Workshop Repairs: Provides a straightforward replacement locknut for compatible metric bolted joints.
M24 DIN 985 Thin Nyloc Hex Nut Dimensions
- Thread Size: M24
- Thread Pitch: 3.00mm
- Across Flats: 36mm
- Height: 24mm
- Material: A2 Stainless Steel
- Standard: DIN 985
Key Benefits
- 36mm across-flats dimension provides the stated hex body width for tool engagement.
- A2 Stainless Steel construction provides the specified metal grade and finish.
- Compact body height suits assemblies where a taller locknut may create clearance issues.
- Self-locking format can reduce the need for a separate locking washer in suitable assemblies.
For help selecting the correct locking nut for your bolted joint, speak with our team on 01233 713581.
