M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel

Product code: THUM464-M4-20-A1
View All Specifications
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
M4 x 20mm Knurled Thumb Screw (DIN 464) | A1 Stainless Steel
Quantity
Unit Price
(ex. VAT)
Unit Price
(inc. VAT)
1 - 24 £1.77 £2.12
25 - 49 £1.56 £1.87
50 - 99 £1.35 £1.62
100 - 499 £1.18 £1.41
500 + £0.96 £1.15

£2.12 / each


Up to 1 units
In Stock
Vital Parts Tick
Order within for same day dispatch.
Up to 1,251 units
Available
Vital Parts Tick
Order now for dispatch within 2 days.
Up to 13,764 units
Available
Vital Parts Tick
Order now for dispatch within 5 days.
13,764 + units
Available for production
Average production time 14 + days.
Vital Parts - Here to make bulk ordering easy.

Product Specification
Thread Size M4
Thread Length 20mm
Pitch 0.70mm
Head Diameter 16.35mm
Head Height 9.5mm
Knurled Height 3.5mm
Shank Diameter 8.0mm
Standard DIN 464
Material A1 Stainless Steel

Next Day or Standard Delivery available via DHL or Royal Mail.
Order by 4pm (UK) for same day dispatch, Monday to Thursday or 2pm Friday.

Larger Order?

Call our sales team on

01233 713581


Frequently Bought Together

Total Price: £0.00

M4 x 20mm Knurled Thumb Screw | DIN 464 | A1 Stainless Steel

Providing quick manual fastening for repeated-access fastening points, this M4 x 20mm knurled thumb screw uses a wide knurled head to transfer turning force through the fingers. The A1 Stainless Steel body and DIN 464 dimensions make it suitable for threaded components used in clamping, levelling and adjustment work. This size is also relevant when comparing knurled fastening screw options for compatible threaded assemblies.

What Are DIN 464 Knurled Thumb Screws?

Knurled Hand Screws are designed for manual fastening into compatible internally threaded components. The DIN 464 form combines a large grip head with a shoulder below the head which can provide clearance from a panel and a contact point for suitable springs or assemblies.

Common Applications

  • Sprung Assemblies: The shoulder beneath the head can provide a contact area or clearance in compatible spring-loaded arrangements.
  • Levelling and Positioning: Can be used in suitable threaded mechanisms where hand adjustment of position or pressure is required.
  • Control Panels: Secures removable panels and covers that may require repeated access for inspection or maintenance.
  • Equipment Housings: Provides an accessible fastening point on machinery covers, cases and instrument enclosures.

M4 x 20mm DIN 464 Knurled Thumb Screw Dimensions

  • Thread Size: M4
  • Thread Length: 20mm
  • Pitch: 0.70mm
  • Head Diameter: 16.35mm
  • Head Height: 9.5mm
  • Knurled Height: 3.5mm
  • Shank Diameter: 8.0mm
  • Material: A1 Stainless Steel
  • Standard: DIN 464

Key Benefits

  • 0.70mm metric pitch matches the specified DIN 464 thread for this size.
  • 9.5mm head height provides the stated DIN 464 head profile.
  • A1 Stainless Steel construction supports repeated manual use and provides corrosion resistance for general engineering applications.
  • Shoulder beneath the head can provide stand-off from the mating surface and suit compatible panel or spring arrangements.

Find other sizes in our DIN 464 Knurled Screw range. If this head style is not the right fit, we also have other products available in our Knurled Fasteners category. If you need help matching the screw to a threaded component, contact our team on 01233 713581.
